Buy Titan lever arms for the exact rack family and generation, then check anchoring and movement clearance. T-3, X-3 and TITAN Series arm sets have different brackets; they are not interchangeable because the manufacturer name matches. Titan recommends using the arms only with a bolted-down rack. The T-3/X-3 leg-press attachment requires a separate compatible arm pair.
Comparisons are based on manufacturer specifications and published product information. US product information checked October 21, 2026. We have not conducted hands-on testing. Prices are dated equipment examples, before tax and any delivery or installation costs.
On a phone, swipe the table sideways to see every column.
| Current arm pair / checked price | Exact family and mounting limit | Dimensions / manufacturer ratings | Required extras |
|---|---|---|---|
| T-3 Adjustable Lever Arms, SKU 400847 $284.97 |
T-3 rack family; explicitly excludes T-3 racks purchased before October 2021. | 39 in arms; 11.5 in posts, 50 mm sleeves; 32 mm grips; 30 lb per arm; 600 lb per arm stated rating. | Compatible bolted-down rack, suitable plates/retention; supported bench or other equipment for planned movements. |
| X-3 Adjustable Lever Arms, SKU 400848 $314.97 |
X-3 family only; verify the exact base/configuration. | 39 in arms; 11 in posts, 50 mm sleeves; 32 mm grips; 45 lb per arm; 600 lb per arm stated rating. | Same basket checks. A flat-foot rack label does not waive Titan’s bolted-down lever-arm recommendation. |
| TITAN Series Adjustable Lever Arms, SKU 400849 $299.97 |
TITAN Series rack family; distinct from X-3 despite nominal 3×3 uprights. | 39 in arms; 11.25 in posts, 49 mm sleeves; 32 mm grips; 42 lb per arm; 600 lb per arm stated rating. | Exact matching rack, anchoring, compatible plates/collars and required exercise supports. |
Compatibility requires more than tube size
The pin-on bracket must fit the upright profile, hole size, mounting face, pin engagement and hole centers. The T-3’s rectangular uprights differ from the square X-3. The TITAN Series uses its own bracket/pin interface. Never use a loose pin, drill an improvised interface or assume a cross-brand fit based on a forum build.
For an older rack, confirm its purchase date and generation from the order or original manual. Current T-3 arms explicitly exclude pre-October-2021 racks. The conversion bracket sold for older X-3 arms is not proof that every older arm or rack can use every current accessory. Obtain the maker’s exact compatibility confirmation.
If you are still choosing a rack, the T-3 vs X-3 model comparison shows an equal-depth complete basket rather than comparing bare frame prices.
Mounting and movement clearance
- Anchor first. Titan recommends a bolted-down rack for lever-arm use. Verify the substrate, anchors and rack instructions; stored plates are not a demonstrated equivalent.
- Install the matched pair as instructed. The manuals identify the bracket, hinge hardware, handle assembly, plate holder and retaining pins. Reposition with the arms unloaded and supported.
- Trace the whole arc. The 39-inch arm length is not a complete depth requirement. Add bracket geometry, handles, the plate radius, body position and room to load both sides.
- Check other rack functions. Arms may occupy the same upright holes or forward area used for J-cups, safeties, a bench or access. Storage and changeover can be the deciding cost.
- At the uprightBracket and pins engage the exact matching holes.
- Across the swingArm, loaded plate and handle clear rack, floor and body.
- Around the stationLeave loading, entry, bench and emergency-exit access.
Leg-press attachment: what you must already own
Titan’s Lever Arm Leg Press, SKU 400485, is a cross-connecting footplate attachment for the T-3 and X-3 system. Its current page states the lever arms are required and sold separately. The 47.5-inch overall width and 37.5 × 11.5-inch footplate do not establish fit on a different rack width. Do not assume TITAN Series compatibility; the listing names T-3 and X-3.
On a phone, swipe the table sideways to see every column.
| Existing setup | Additional checked equipment | Equipment subtotal |
|---|---|---|
| Compatible, appropriately anchored T-3 rack; no arms | T-3 pair $284.97 + leg-press attachment $169.97 | $454.94 |
| Compatible, appropriately anchored X-3 rack; no arms | X-3 pair $314.97 + leg-press attachment $169.97 | $484.94 |
| Compatible arms already owned | Leg-press attachment $169.97 | $169.97, after exact compatibility confirmation |
Add suitable plates, collars, maker-supported body/bench arrangement, anchoring or installation work, delivery and tax. The attachment’s 1,200 lb rating and arm pair’s per-arm ratings do not make the rack or whole leg-press setup a certified 1,200 lb system. The lowest applicable component limit and intended configuration govern.
Should you buy them?
Buy a matched pair when you will use the lever pattern frequently, can anchor the rack and can accommodate the complete swing/loading area. Skip or defer when repeated changeovers would block your main squat/bench setup, when compatibility is unresolved or when you mainly want a dedicated leg press. Compare standalone leg press and hack squat machines before turning a rack into a station it was not configured to support.
Plate weight is not equal to hand force: pivot distance and handle position change the mechanical relationship through the arc. Do not translate a barbell load or another machine’s stack number directly into a first lever-arm working weight.
Sources and comparison method
Exact configurations and manuals control the comparisons below. Manufacturer load ratings and comfort or stability descriptions are claims, not independent test results. Product photos, versions, prices and included parts can change.
